Dell Optiplex GX280: Turning an Office Box Into an XP Gaming PC

The Optiplex GX280 was a beige-and-grey office PC from the Pentium 4 years. Thousands of them sat under desks running spreadsheets. That makes them cheap and easy to find now, and a decent starting point for a Windows XP gaming box, as long as you fix the things Dell never meant it to do.

This is my plan for that. Every part below was picked for a specific weakness in the stock machine, and they're in the order I'd install them.

What the stock machine is missing

Area	Stock
Platform	Intel Pentium 4
RAM	Not much of it
Graphics	Basic integrated
Power supply	Stock Dell unit
Audio	Nothing dedicated

The integrated graphics are the real problem for games. But you can't just drop a graphics card in, because of the power supply. So the plan starts there.

The parts, in order

Phase	Part	Why
1. Power	KDMPOWER 480W PSU for the GX280 SMT (mid tower 50N compatible)	Stable power for the graphics card
2. Audio	Dell AS500 clip-on monitor sound bar	Better sound without eating desk space
3. Graphics	XFX GeForce 9800 GT, 512MB	Solid DirectX 9 and 10 performance
4. Storage	Samsung 840 Pro SSD, 256GB	Fast boots and load times
5. Maintenance	Silver thermal paste, 10g tub	Better CPU temps
6. Memory	Super Talent DDR2-533, 512MB	More headroom for multitasking

Everything on the list is used and from eBay, and it priced out at $126.62 including shipping at the time. The two biggest line items were the PSU and the graphics card. The SSD, oddly, was one of the cheapest things on the list. Older SATA SSDs like the 840 Pro are a bargain used.

Why the PSU leads. Most 9800 GT cards want a 6-pin PCIe power connector, and a stock office PSU usually doesn't have one or doesn't have the headroom. Putting a new card on a marginal supply is how you get random crashes that look like driver problems. So new power first, card second.

Tip

Check which GX280 you've got before you buy a PSU. Dell made it in several case sizes, and the replacement supply has to match yours. The PSU on my list is the one made for the SMT (small mini-tower).

The 9800 GT is a sweet spot for XP. It's old enough that XP drivers are mature and new enough to run pretty much anything from the XP era at high settings. The Dell AS500 is a small, silly, period-correct touch: a speaker bar that clips onto the bottom of a Dell monitor.

Heads up

Windows XP doesn't know what TRIM is, so an SSD won't get the housekeeping it gets on a modern OS. For a machine that mostly boots and loads games, I'm fine with that. Just leave some free space on the drive.

What it should be good for

If it all goes together the way it should, the GX280 ends up with reliable power, a real graphics card, SSD storage, a speaker, better cooling and more RAM. That's enough for:

• Windows XP era gaming
• Light productivity
• Basic multimedia
• Period-correct software

It won't be the fastest XP machine anyone's built. A Pentium 4 is a Pentium 4. But the point is running the games of that era on hardware from that era, without paying collector prices.

Where it stands

This is the build list and the order I'm following. I'll write up how the install actually goes, including whether that PSU fits as cleanly as the listing promised, once it's all in.

The eMac upgrade plan is the same idea on the Mac side, and the T7500 workstation plan is the opposite end: an old machine that needs more storage, not more games.
